PFOA PFOS EPTFE Vent Membrane Expanded Ptfe Membrane High Reliability
Key Attributes
Brand Name:
XINXIA
Place of Origin:
CHINA
Certification:
ISO9001
Minimum Order Quantity:
5000pcs
Price:
2-5RMB/PCS
Supply Ability:
500000PCS/DAY
Delivery Time:
5-8 working days
Payment Terms:
T/T
Standard Packaging:
Corrugated Carton / Box
Product Summary
Automotive & Electronics Vent Membrane ePTFE Vent membrane XINXIA-G180WO Ensure the reliability and longevity of your sensitive electronics with our high-performance vent membranes. Designed to balance pressure and block contaminants, these membranes are ideal for demanding automotive and electronic...
Product Custom Attributes
Highlight
PFOA Vent Membrane
,PFOS Vent Membrane
,expanded ptfe membrane high Reliability
PRODUCT NAME:
Automotive & Electronics Vent Membrane
PRODUCT MODEL:
XINXIA-G180WO
PRODUCT DESCRIPTION:
E-PTFE Oleophobic And Hydrophobic Breathable Membrane
APPLICATION FEILD:
Automotive & Electronics
APPLICATION PRODUCTS:
/
PHYSICAL PROPERTIES:
PFOA & PFOS
REFERED TEST STANDARD:
US EPA 3550C & US EPA8321B
UNIT:
℃
TYPICAL DATA:
PFOA & PFOS Free
Product Description
Automotive & Electronics Vent Membrane
ePTFE Vent membrane XINXIA-G180WO
Ensure the reliability and longevity of your sensitive electronics with our high-performance vent membranes. Designed to balance pressure and block contaminants, these membranes are ideal for demanding automotive and electronics applications.
Key Benefits:
- Pressure Equalization: Maintains optimal pressure balance inside sealed enclosures.
- Contaminant Blocking: Prevents dust, water, and other contaminants from entering.
- Increased Reliability: Enhances the reliability of electronic components.
- Extended Service Life: Prolongs the lifespan of your products.
- Versatile Applications: Suitable for automotive lamps, outdoor lighting, and various electronic devices.
Target Industries: Automotive, Electronics, Outdoor Lighting, Household Appliances
Product Attributes
FOB Unit piece
MOQ Not specified
FOB Price 0
Packaging & Delivery Not specified
Technical Specifications
| Property | Test Standard | Unit | Typical Data |
|---|---|---|---|
| Product Name | - | - | Automotive & Electronics Vent Membrane |
| Product Model | - | - | XINXIA-G180WO |
| Product Description | - | - | e-PTFE Oleophobic and Hydrophobic breathable membrane |
| Application Field | - | - | Automotive & Electronics |
| Application Products | - | - | / |
| Membrane Color | / | / | Dark Gray |
| Membrane Construction | / | / | PTFE |
| Membrane Surface Property | / | / | Oleophobic/Hydrophobic |
| Thickness | ISO 534 | mm | 0.19±0.05 |
| Interlayer Bonding Strength (90 degree peel) | Internal Method | N/inch | NA |
| Min Air Flow Rate | ASTM D737 (Test area:1 cm²) | ml/min/cm²@ 7Kpa | >250 |
| Typical Air Flow Rate | ASTM D737 (Test area:1 cm²) | ml/min/cm²@ 7Kpa | 500 |
| Water Entry Pressure | ASTM D751 (Test area:1 cm²) | KPa for 30 sec | >40 |
| IP Rating | IEC 60529 | / | IP68 |
| Water Vapor Transmission Rate (evaporation) | GB/T 12704.2 (38℃/50%RH ,Cupping method) | g/m2/24h | >5000 |
| Oleophobic Grade | AATCC 118 | Grade | ≥7 |
| Operation Temperature | IEC 60068-2-14 | ℃ | -40℃ ~ 260℃ |
| ROHS | IEC 62321 | / | Meet ROHS Requirements |
| PFOA & PFOS | US EPA 3550C & US EPA 8321B | / | PFOA & PFOS Free |
